2.5 - 10m Inductive Proximity Sensor , Industrial Control Ultrasonic Level Switch

Name: 25 10m Inductive Proximity Sensor Industrial Control Ultrasonic Level Switch
Brand: HAOLI
Price: 1 USD

Brand Name : HAOLI

Certification : CE，ISO9001，ROHS

Place of Origin : ChengDu

MOQ : 500

Price : Negotiation

Payment Terms : TT

Delivery Time : 8 Work Days

Teach-in-range(mm) : 25-400

Resolution(mm) : 0.5

Frequency(KHZ) : 300±5

Connector : M12

Temperature Drift : 1.5% of full scale

Protect Class : IP67

Contact Now

M18 175KHZ Ultrasonic Proximity Switches Industrial Control Sensor

Description

The ultrasonic proximity switch detects any object from 2.5cm to 10m. Ultrasonic proximity switches are used to detect objects of different materials, shapes, colors or concentrations with excellent accuracy, flexibility and reliability. Its application range is very wide. Whether it is level measurement or height measurement, whether it is distance measurement or bottling count, whether it is 2.5cm or 10m, objects with different characteristics can be detected. And it can be solid, liquid, powder, or even a transparent object. The inspection is independent of the nature of the surface and the surface can be rough or smooth, clean or dirty, wet or dry. The proximity switch sensor is very rugged and insensitive to dirt, ambient light or noise.

feature

Measurement accurate to millimeters
Unaffected by color and materials, even transparent objects can be detected
Individual parameter setting
Compact, compact housing (M18S)
High repeatability
Worldwide use: UL/CSA certification
Insensitive to temperature, noise, light or water

Application

Fill level and height sensing
Interval measurement
Coil diameter sensing
Bottle count
Size measurement
Material stack height measurement
Diameter and speed measurement
Contour measurement

Specification

Diameter	M18
Tech-in-range(mm)	60-1500
Resolution(mm)	0.1
Frequency(KHZ)	175±5
Operating Voltage	10VDC
Ripple	<10%
No Load Current(mA)	<50
Max.Load Current(mA)	150
Leakage Current	<0.1mA
Voltage Drop	<3V
Response Delay	108ms
Output	PNP,NPN,4-20mA,0-5V,0-10V
Protection Category	IP67
Operating Temperature	-25°C - +70°C
Temperature Drift	<1.5%(Sr)
Short Circuit Protection	YES
Overload Trip Point	180mA
Determination	63 * Ø18 mm
